Lock Size: 215x30Wx37H(mm)
inbuilt size: 170Lx25WX34H(mm)
latch plate: 90L*25W*3H(mm)
Bolt: 14 mm Dia. 12.5mm 12VDC (DC24V OEM)
Start Current: 1200mA Standby Current: 200mA
Door magnetic feedback signal NO/COM
Time Delay: Yes, 0,3,6,9sec Cable: 750mm
Unlocked (LED Green), locked (LED Red)
For: Woodming Door/Glass Door,Metal Door Fireproof Door
Special Designed: Tested to 500000 cycles
Zinc alloy with Keys
Weight: 0.75 kg
