Holding 1000kg.
Special design,easy to adjust the distance of the Lock-tongue.
Designed for Metal Frame drill a hole,then install it directly.
Testing to 500000 cycles.
High-Temperature Painted,Durable and Beautiful Artical.
CE Certificate by European Union.
Lock Size:250Lx43.7Wx35H(mm)
Strike Structure: Stainless Steel
Holding Force: 1000kg
Voltage:DC12V (Need Order DC24V)
Current：12V/320mA;24V/160mA
Feature： Fail Secure(YS-138LKNO-S); Fail Safe(YS-138LKNC-S)
Suitable For： Wooden Door,Metal Door,PVC Door
Signal Output： Door status Output,NO/NC/COM
Surface Temperature： Within +20℃
Suitable Temperature： -10~+55℃(14-131F)
Operating Humidity： 0～90%(non-condensing)
Face plate Housing： Painted Steel
Function： Built-out MOV
Weight： 0.42kg
